JOES Micro Sprint Chassis Bolt Kit

$249.95

Steel hardware too heavy for you? Smith Titanium provides a stronger, lighter solution to your hardware needs. Click here for more details.

Out of stock

Want to be notified when this product is back in stock?

Complete Bolt Kit for Micro Sprint Chassis

JOES Micro Sprint Bolt Kit fits Farrell Chassis

Wing

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
4	¼”-28 x ¾”	Front Wing to Front Wing Post	9010010
2	¼”-28 x ¾”	Front Wing to car, Rear Mount	9010010
2	10″-32 x 1¼”	Front Wing Post to Clamp	9020735
2	10″-32 Nylock Half Nut	Front Wing Post to Clamp	9010760
2	⁵/₁₆”-24 x 1½”	Top Wing, Pinch Clamp	9010070
1	⁵/₁₆”-24 x 1″	Wing Tree to Frame	9010068
1	⁵/₁₆”-24 x 1½”	Wing Tree to Frame	9010070
1	⁵/₁₆”-24 x 1½”	Wing Tree to Wing, right	9010070
1	⁵/₁₆”-24 x 2″	Wing Tree to Wing, left	9010069
1	¼”-28 x 1¼”	Wing Slider to Frame	9010014
6	⁵/₁₆”-24 Nylock Full Nut	For above bolts	9010662
7	¼”-28 Nylock Half Nut	For above bolts	9010636

Steering

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
2	⁵/₁₆”-24 x 3″	Steering Box to Frame	9010073
1	⅜”-24 x 1¾”	Draglink to Steering Box	9010099
1	⅜”-24 Nylock Full Nut	Nut for Draglink Bolt	9010676
2	⁵/₁₆”-24 x 2″	Steering Gear Plate to Frame	9010069
2	⁵/₁₆”-24 Nylock Full Nut	Steering Gear Plate to Frame	9010662
3	⁵/₁₆”-18 x ½”	Steering Wheel to Quick Release Hub	9010046
2	⅜” ID x ½” Radius Spacer	Steering Gear to Draglink	25621

Front End

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
3	⅜”-24 x 1¼”	Radius Rod to Axle	9010095
3	⅜”-24 Nylock Half Nut	Radius Rod to Axle	9010677
3	⅜”-24 x 1¼”	Radius Rod to Frame	9010095
4	⅜”-24 x 1″	Shock Mount	9010094
1	⅜”-24 x 2¼”	Panhard Bar	9010107
2	⅜”-24 Nylock Half Nut	Panhard Bar	9010677
2	⅜”-24 x 2¾”	Tie Rod to Combo Arm, left	9010108
1	⅜”-24 x 2″	Tie Rod to Combo Arm, right	9010106
2	⅜”-24 Nylock Full Nut	Tie Rod to Combo Arm	9010676
4	⅜”-16 x 1¼”	Combo Arms to Spindles	9010088
2	⁵/₁₆”-18 x 2″	Torsion Arm Pinch Bolt	9010058
2	⁵/₁₆”-18 Nylock Full Nut	Torsion Arm Pinch Bolt	9010642
1	⅜” ID x ¼” Radius Spacer	Combo Arm to Draglink/Tie Rod	25620

Rear End

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
2	⁷/₁₆”-20 x 1¼”	Radius Rod to Birdcage	9010114
2	⁷/₁₆”-20 x 1¼”	Radius Rod to Frame	9010114
1	⁷/₁₆”-20 x 1¼”	Brake Rod to Caliper Carrier	9010114
1	⁷/₁₆”-20 x 2¾”	Brake Rod to Frame	9010120
1	⁷/₁₆”-20 Nylock Half Nut	Brake Rod to Frame	9010682
2	SHCS ⅜”-24 x 1½”	Caliper to Carrier	9020822
2	⅜”-24 Top Lock Nut	Caliper to Carrier	9010675
2	⅜”-24 x 1¾”	Shock to Rear Arm	9010099
2	⅜”-24 Nylock Half Nut	Shock to Rear Arm	9010677
2	⅜”-24 x 2″ Custom Bolt	Rear Arm to Birdcage	925872-2
2	⁵/₁₆”-18 x 2″	Rear Arm Pinch Bolt	9010058
2	⁵/₁₆”-18 Nylock Full Nut	Rear Arm Pinch Bolt	9010642
2	⅜”-24 x 1¼”	Upper Shock Mount	9010095
2	⅜”-24 x 1¾”	Ladder to Straps	9010099
2	⅜”-24 Nylock Half Nut	Ladder to Straps	9010677
2	⅜” x 1¾” Clevis Pin	Ladder Straps to Frame	9010915
1	⅜” x 1⅛” Clevis Pin	Ladder to Birdcage	9010914
3	Circle Clip	Clips to Pins	9010901
2	Spring	Spring for in-between Ladder Strap	9012323
1	⅜”-24 Steel Heim, RH	Side of RR Birdcage	9011401
1	⅜”-24 Jam Nut, RH	Jam Nut for ⅜” Heim	9011403
2	⁷/₁₆”-20 Steel Heim, RH	Rear Arm	9011410
2	⁷/₁₆”-20 Jam Nut, RH	Jam Nut for ⁷/₁₆” Heim	9010686
2	⁵/₁₆”-18 x ⅞” FHCS	Chain Guide to Birdcage	9020830
2	⅜”-24 x 1″ Hex Bolt	Frame to Shock	9010094

Cockpit

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
2	⅜”-24 x 1½”	Pedals to Frame	9010097
2	⅜”-24 Full Jam Nut	Pedal Mount Pinch Nut	9010669
2	⁵/₁₆”-24 x 1¾”	Master Cylinder to Frame Mount	9010071
2	⁵/₁₆”-24 Nylock Full Nut	Master Cylinder to Frame Mount	9010662
1	⅜”-24 x 1¼”	Shifter Mount	9010095
1	⅜”-24 Nylock Half Nut	Shifter Mount	9010677
2	¼”-28 x 1″ SHCS	Shift Cable to end of Shift Lever	9020552
1	¼”-28 x 1″	Bellcrank to Frame	9010013
5	¼”-28 x 1″	Pedal Linkages	9010013
5	¼”-28 Nylock Half Nut	Pedal Linkage	9010636

Fuel Tank

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
12	¼”-28 x 1″	Top Filler Plate	9010013
12	Washer, Flat Nylon	Top Filler Plate	9023034
4	⁵/₁₆”-24 x ¾” SHCS	Tank Mount to Frame	9020841
4	⁵/₁₆” Ext Tooth Star Washer	Tank Mount to Frame	9023075
4	⁵/₁₆” x ¾” OD Flat Washer	Tank Mount to Frame	9023073

Miscellaneous Hardware

QTY	FASTENER	LOCATION DISCRIPTION	JOES P/N
14	10″-32 x 1¼” SHCS	Nerf Bolts	9020735
14	10″-32 Nylock Nut	Nerf Bolt Nuts	9010763
2	¼”-28 Female Heim, RH	Shift Cable Ends	9011405
2	¼”-28 Jam Nut, RH	Shift Cable Ends	9010638
4	⅜”-24 x 1¾”	Engine Plates to Frame	9010099
1	⁷/₁₆”-20 x 3½”	Upper Engine Mount to Frame	9010121
1	⁷/₁₆”-20 Nylock Full Nut	Upper Engine Mount to Frame	9010682
1	⅜”-24 x 1″ FHCS	Chain Roller Mount	9020815
1	⅜”-24 Nylock Half Nut	Chain Roller Mount	9010677
